Model number : GC-E100

Gesture control

The GC-E100 is a fully functional gesture control solution for all types of lamps. The complete functionality of the GC-E100, starting from the gesture recognition up to the controlling of the illumination is implemented and merged together. Alternative settings allow a customized solution for individual concepts and innovative products.

Specification :

Features
-> Advanced ready-to-use functions
-> On/Off – The lamp shines with 100% brightness (on) or with 0% (off).
-> Dimming – The lamp shines with a brightness in between 0% and 100%. Step size is 0.4%.
-> Acknowledge – Indication of a status change by a variation of the brightness. If the brightness is < 50% it will increased by 30% if it is > 50% it will decreased by 30%.
-> Detection range approx. 30cm
-> PWM-Output for innovative motion-controlled lighting application
-> IR Distance : 30 cm (max)
-> Dimension : 30 x 20 x 10 mm
